Drivemotion Sb-4Dd Agm Standby Battery – 12V, 200Ah, General Purpose

Description

SB-4D – 12V 200Ah AGM Battery for UPS, Medical, and Standby Systems

Reliable Long-Life Power for Critical Backup Applications

The SB-4D 12V 200Ah battery is part of the General Purpose/Standby Series, engineered for dependable float service with a design life of up to 12 years. Built with advanced AGM (Absorbent Glass Mat) VRLA technology and high-purity materials, it’s ideal for applications such as UPS/EPS systems, medical equipment, emergency lighting, and security systems.

This UL-recognized battery meets IEC and JIS standards and is manufactured under ISO-certified facilities, ensuring quality and safety across a wide range of environments.

🔋 Key Features:

• Battery Type: AGM VRLA – Maintenance-Free, Spill-Proof
• Nominal Voltage: 12V
• Capacity: 208Ah @ 20Hr, 202Ah @ 10Hr, 171.2Ah @ 5Hr
• Design Life: 12 Years (Float Use)
• Maximum Discharge Current: 2000A (5 seconds)
• Low Self-Discharge: Approx. 3% per month at 25°C
• Terminal Type: F12 (M8)
• Operating Temperature: -40°C to 60°C (Discharge)

📏 Dimensions & Weight:

• Size: 532 x 207 x 219 mm (20.94 x 8.15 x 8.62 inches)
• Weight: Approx. 51.5 kg (113.5 lbs)

⚡ Charging Guidelines:

• Float Charge Voltage: 13.6V–13.8V @ 25°C
• Cyclic Charge Voltage: 14.6V–14.8V @ 25°C
• Max Charging Current: 54 Amps
• Temperature Compensation: Adjust voltage by -3mV/°C per cell (float) or -4mV/°C (cyclic)

✅ Certifications & Manufacturing:

• UL Recognized Component (MH60449)
• Complies with IATA/ICAO Special Provision A67 (Air Transport Approved)
• Manufactured in ISO 9001, ISO 14001, OHSAS 18001 certified facilities

📦 Applications:

• Uninterruptible Power Supplies (UPS/EPS)
• Medical and Emergency Lighting Equipment
• Security and Monitoring Systems
• Telecom and Standby Power Systems

⚠️ Important Notice:
Never install AGM batteries in airtight enclosures. Avoid short-circuiting terminals or mixing batteries of different age or type. Please note: We only supply the batteries shown in the images. Images of compatible equipment are shown for reference only.

Proper charging is essential for long service life. Follow the guidelines provided to avoid overcharging or undercharging. Under ideal conditions, maintaining around 50% Depth of Discharge (DOD) provides the best lifespan for AGM batteries.
