Description
HCST209-28 bearing is a 1-3/4″ bore normal-duty take-up bearing that utilizes an eccentric locking collar to secure to a 1-3/4″ shaft. HCST209-28 take-up bearings are designed for take-up frames, which creates an assembly that maintains and adjusts tension for conveyor and drive systems. Our superior HCST209-28 bearing with a 1-3/4″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid cast-iron housing. Additionally, our HCST209-28 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. Our HCST209-28 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCST209-28 bearings, and we will be happy to assist you!
HCST209-28 Take-Up Bearing Dimensions
- Part #: HCST209-28
- Shaft Diameter (d): 1-3/4″
- Dimension (O): 0.75″
- Dimension (G): 0.63″
- Dimension (P): 3.25″
- Dimension (Q): 1.94″
- Dimension (S): 1.13″
- Dimension (B): 3.25″
- Dimension (K): 0.69″
- Dimension (E): 4.00″
- Dimension (A): 4.63″
- Dimension (W): 5.69″
- Dimension (J): 1.94″
- Dimension (L): 1.38″
- Dimension (H): 3.44″
- Dimension (Bi): 2.2165″
- Dimension (N): 0.8425″
- Dimension (M): 0.8425″
- Dynamic Load Rating (LBS): 7,160
- Static Load Rating (LBS): 4,676
- Bearing Insert: HC 209-28
- Housing Number: ST 209-26
- Weight (LBS): 5.7
